The 2025 BIOS/UEFI Optimization Handbook: Safe Settings That Actually Help

Promise: No “OC roulette.” This handbook focuses on vendor-documented features that are safe, reversible, and deliver repeatable gains: Resizable BAR, Above 4G Decoding, PBO/Curve Optimizer (AMD), TVB/ABT (Intel), memory context options, and power/thermal ceilings.

Step 1 — Update BIOS & set a rollback plan

• Flash the latest stable BIOS for memory/USB4/PCIe fixes.
• Back up current settings. If you crash, clear CMOS and reload last known-good.

Enable Resizable BAR correctly

Why: Lets the CPU address the full GPU framebuffer; many titles see a small uplift for free.

1. Disable CSM/legacy boot. Enable Above 4G Decoding and Resizable BAR (Smart Access Memory on AMD). Save & reboot.
2. Update GPU drivers and (if required) VBIOS.
3. Verify enablement in GPU-Z or the vendor control panel.

Memory: fast and stable

Start with XMP/EXPO, then make small, conservative tweaks. See our XMP vs EXPO playbook for a step-by-step. Validate with long mixed workloads, not just quick benchmarks.

AMD: Precision Boost Overdrive (PBO) & Curve Optimizer (CO)

• What they do: PBO lifts power/current limits; CO offsets the V/F curve per core to reduce voltage for a given frequency.
• Safe start: PBO “Enabled/AMD Spec.” Try CO negative −5 to −15 on best cores; test all-core/single-thread/gaming. Keep CCD temps in check; consider Eco Mode for small coolers.

Intel: Turbo policies that help

Thermal Velocity Boost (TVB) and related turbo policies add bins when thermal headroom exists. Ensure your cooler can sustain it, and set sensible PL1/PL2 limits for noise-normalized performance.

Memory training & boot time (AM5)

Memory Context Restore and “Power Down” cache the last successful training to speed boot. Enable only after stability is proven—bad cached params can hide marginal OCs.

Power/thermal ceilings

Set a firm CPU temperature target (e.g., 85–90 °C). You’ll trade a couple points of peak for steadier clocks and much better acoustics.

Checklist

• ✔ BIOS up to date; chipset/GPU drivers current.
• ✔ UEFI boot, Above 4G, Resizable BAR.
• ✔ XMP/EXPO → long mixed stability tests.
• ✔ AMD: PBO “Enabled/AMD Spec”; CO small negative per-core; re-test.
• ✔ Intel: TVB/ABT on (within cooler limits); sensible PL1/PL2.
• ✔ Enable Memory Context Restore only after proving stability.

Related BonTechLabs reads

• Memory tuning playbook
• VRAM explained (2025)
• N2 node explainer

Sources

• NVIDIA: Resizable BAR requirements
• Intel: Thermal Velocity Boost overview
• AMD Ryzen Master user guide
• ASUS: How to enable Resizable BAR
